FollowingĪre the basics for installing a door chime. And if you are not comfortable making the basicġ20-volt wiring connection to the transformer, then complete all the low-voltage wiring and call in an electrician to connect the transformer. However, if your circumstances make fishing wires too difficult, consider installing a wireless system. If your basement or crawl-space ceiling is open (unfinished), the task usually is quite doable, even for a beginner. Feeding the wires behind closed walls between the components, a process called fishing, is the only potentiallyĭifficult task in this installation. This project has you covered whether you need to install a door chime from scratch (including button, chime, and transformer), add a button to a secondĭoor, or just replace or upgrade a component.
